Template/Scrapper Necking-in and Bottom Closing Hot Spinning Machine for CNG Cylinders^

Quantity:
  • HLT

  • Steel

  • Orbital Models (BM Series)

  • Hot Spinning

  • Cylinder

  • Cylinder Shape

  • Ltm140

  • 76-180mm

  • 330-1100mm

  • 2-15mm

  • 1000mm

  • 90kw

  • 90

  • 30mm

  • PLC

  • 34CrMo4 (35CrMo), 37mn, 30CrMo, 45#, 20#

  • 80s

  • 260-520 R/ Min

  • Necking-in and Bottom Closing Hot Spinning Machine

  • Standard Seawood Package

  • 116000*2000*1300mm

  • LTM

  • Jiangsu, China

  • 8463900090

  • 500 Sets/Year

  • Available | Customized Request

Product Description

Template/Scrapper Necking-in and Bottom Closing Hot Spinning Machine for CNG Cylinders^
Template/Scrapper Necking-in and Bottom Closing Hot Spinning Machine for CNG Cylinders^
Product Description

The template type hot spinning machine uses molds to extrude and heat the rotating work piece to shape it, and most of the machine has aspherical bottom or a dish-shaped bottom.

Forming process:
Tube blank preheating→feeding→clamping→spindle rotation→spinningprocessing→spindlestop→discharging.

On the mold where the template type spinning machine and the work piece are in direct contact, a traditional plate mold is used to extrude the work piece to deform the tube blank.

Product Parameters
Item
value
Place of Origin
China Jiangsu
Brand Name
LTM
Condition
New
Machine Type
Template structure + thimble with mold
Video outgoing-inspection
Provided
Machinery Test Report
Provided
Core Components
PLC
Key Selling Points
High Productivity
Applicable Industries
Machinery Repair Shops, Manufacturing Plant
Application
Heating
Usage
Forming
After-sales Service Provided
Engineers are available
Raw material
CNG cylinder, Seamless Cylinder, Industrial Cylinder
Power
110

Φ140 Hot spinning machine (Template structure + thimble with mold)
Diameter range: φ76~140mm
Length range:330~1100mm (The max length of the tube is 1250mm)
Thickness range:<10mm
Weight:<80kg
Production speed: < 80s
Spindle speed: 260~520 r/ min
Template/Scrapper Necking-in and Bottom Closing Hot Spinning Machine for CNG Cylinders^

Φ275 Hot spinning bottom retracting machine (Template structure)
Template/Scrapper Necking-in and Bottom Closing Hot Spinning Machine for CNG Cylinders^
1. Intermediate frequency heating furnace;
2. Water cooling system;
3. Scraper host;
4. The thimble belt;
5. Slag dumper;
6. Bottom pressing machine;
7. Pure water cooling tower
8. Burning racks and other auxiliary machines and transition racks
9. 1 set φ267mm holding fixture


The way host spindle chuck clamping: Did not appear the axial sliding after clamping , clamping force can be adjusted according to the need. Clamping force ≤180KN.

Hydraulic station: molding-bottom device. scraping- bottom device ,sliding-table and chuck device adopt independent hydraulic system. Tank cooling use heat transfer.

Electric control parts adopt famous brand products The frequency converter and PLC are adopted in the corresponding products of Delta Electronics.
Template/Scrapper Necking-in and Bottom Closing Hot Spinning Machine for CNG Cylinders^
Template/Scrapper Necking-in and Bottom Closing Hot Spinning Machine for CNG Cylinders^
Template/Scrapper Necking-in and Bottom Closing Hot Spinning Machine for CNG Cylinders^

Main Engine Intermediate Frequency Frame Hydraulic Station


The swing mould to form bottom and neck have water cooling device.

The sliding table with scraper (mould) have thickening function .the scraper can run more than once at horizontal and vertical on the basis of setting parameters in the touch screen at any time.
Template/Scrapper Necking-in and Bottom Closing Hot Spinning Machine for CNG Cylinders^
Template/Scrapper Necking-in and Bottom Closing Hot Spinning Machine for CNG Cylinders^
Working Details Finish Products

Location mode of workpiece adopts the back of the positioning for product conformance The positioning length can be manually adjusted according to the requirements .

By replacement of the tooling, mould and adjusting the process parameters, can be quickly implemented different specification products.

That machine is for bottom forming and bottom pushing. If you want to save cost, you can also use the machine to form the mouth when you change the moulds.
