Steel Oil Drum Automatic Three Color Liquid Painting Machine

Quantity:



Inquire Add to Basket

Model NO.:
HLT19-22
Production Scope:
Product Line
Product Name:
Drum Auto Three Color Liquid Painting Machine
Model:
Thg622, Thg660, Thg720, Thg920
Diameter:
406-920mm
Length:
5500-12500mm
Thickness:
10-30mm
Height:
1300mm
Power:
200-355kw
Moving Angle:
90°
Control:
CNC
Dimension:
23000*3200*2300mm
Transport Package:
Standard Seaworthy or Air Package
Specification:
SGS
Trademark:
HLT
Origin:
China, Jiangsu
HS Code:
730799000
Production Capacity:
50000000m/Year
Samples:
US$ 0/Piece 1 Piece(Min.Order) | Request Sample

Product Description

Product Description

Steel Oil Drum Automatic Three Color Liquid Painting Machine

Main Parameter
* 4 sets pray pump(Chongqing Changjiang)
* 13 sets pray nozzle(American Nordson)
* 4500*3400*2500mm painting booth
* Stainless steel sink and paint pipe line
* Edge curl and paint repair device
* Three-jaw painting rotation clamping device

Steel drum production line
1. Drum body traightening & blanking line(Cap straightening line)
Sheet thickness:0.8~1.2mm, Sheet coil width:660~1250mm
Max coil diameter:1650mm, Coil ID:φ508/φ610
Coil weight≤10T, Decoiler speed: 5-50m/min
Mitsubishi PLC, Servo motor driving control

Steel Oil Drum Automatic Three Color Liquid Painting Machine

2. Automatic cap folding machine(with glue), speed: 6pcs/min

Steel Oil Drum Automatic Three Color Liquid Painting Machine

3. Drum body flanging and expanding machine, speed: > 6pcs/min
The drum will be loaded to the machine automatically through conveyor, the machine will automatically check the drum body and lift it to a suitable places, then the carriage plate will move forward, the drum body will be flanged and expanded, then automatically lift down, the carriage plate will automatically move back(when the carriage plate is back, the machine decompression will be loading state, which will save energy). The drum body will go down and be unloaded on the conveyor.
Machine size: 3800*710*1600mm
Machine weight: 5000kgs
Power: 18KW
Capacity:>6pcs/min

Steel Oil Drum Automatic Three Color Liquid Painting Machine

4. Drum assembly machine, speed: >6pcs/min
Manually put the cap on the assembly machine, the conveyor will load on the cap and drum body into the machine and assembly together. The assembly machine adopts double motors, separate driving, double main spindles. The carriage plate adopts imported linear guided with high accuracy and small friction.
Machine size: 3800*900*1700mm
Machine weight: 9000kgs
Power: 55KW
Capacity:>6pcs/min

Steel Oil Drum Automatic Three Color Liquid Painting Machine

5. Painting booth
4 sets pray pump(Chongqing Changjiang)
13 sets pray nozzle(American Nordson)
4500*3400*2500mm painting booth
Stainless steel sink and paint pipe line
Edge curl and paint repair device
Three-jaw painting rotation clamping device

Steel Oil Drum Automatic Three Color Liquid Painting Machine
