Mechanical Decoil, Straightening and Blanking Line For LPG Cylinder Mnaufacturing

Material thickness: 0.6-6mm
Material width: 200-1300mm
Material feeding speed: 16m/min
Material ID/OD: 508mm/1500mm
Straightening roller: ¢90(Up 5 low 4), with one set support roller
Material conveyor: ¢115*1 set, with one set support roller
Coil weight: Max. 15Ton

Quantity:
  • HLT 400/500
  • Longterm
  • 8462291000

Product Description

Mechanical decoiler, straightening and blanking line

Material thickness: 0.6-6mm

Material width: 200-1300mm

Material feeding speed: 16m/min

Material ID/OD: 508mm/1500mm

Straightening roller: ¢90(Up 5 low 4), with one set support roller

Material conveyor: ¢115*1 set, with one set support roller

Coil weight: Max. 15Ton

Feeding direction and height can be adjustable.

Straightening adjust: servo driven, digital show.

Rack motor: 7.5KW, servo motor: 7.5KW

Feeding trolley working table size: 1250*800mm

Feeding trolley lifting distance: 350mm(suitable for 1000-1500mmOD coil)

Main electric components brand:

1_副本

4_副本


No

Description

Brand

1

Photo electricity material arc control system

Taiwan Yangming

2

Coil rack converter

Taiwan Shilin

3

Main release air cylinder

Airtac

4

Pneumatic electromagnetic valve

Airtac

5

Straightening bear

Japan NSK

6

Servo driver

Japan YASKAWA

7

Servo motor

Japan YASKAWA

8

Touch screen - 7 inch

MCGS

9

PLC program controller - FX

Mitsubishi

10

Breaker

Zhejiang Zhengtai

11

Contactor

Schneider

12

Control button

Schneider

13

Relay

Omron

14

Cycloidal pin wheel reducer

Zhejiang Yongjia



Our Service

* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
* Training how to install the machine, training how to use the machine.
* Engineers available to service machinery overseas.


FAQ

LPG cylinder manufacturing equipment
Q: What size of LPG cylinder your machine can produce?
A: 6kg, 12kg,15kgs and 50kgs LPG cylinder for cooking and other size according customers' requirement.

Q: Can you design machines according LPG cylinder technical drawing?
A: Sure, please send your technical drawing to us.

Q: What are the benefits to choose your machines?
A: Our machines are strong and reliable for long term industrial manufacturing

To enable me give you correct proposal for correct machines, please tell me following details:
We need to know following information to quote you correct machineries:
1.Technical Drawing of the cylinders you want to make?
2.What size of cylinder you want to produce?(6kg, 12kg)
3.What diameter and thickness of the cylinder you want to make?
4.Are you new in this area or you already have some machines in the workshop?
5.Capacity you require, i.e. how many pieces and sizes you want to make per day?
