Comflex
Pipe Production Line
0.18-0.3mm
0.15-0.3mm
DN8-40
Unlimited Length of Hose
2.5~3.5m/Min
SUS304, 321 and 316L
5kw
8000*1100*1700
380V/415V
Standard Seaworthy Package Plywood Box
ISO9001
Comflex
Jiangsu, China
844790900
2000 Sets Per Year
Available | Customized Request
Product Description
No. | Size | Tube OD (mm) | Wall thickness (mm) | Hose ID (mm) | Hose OD (mm) | Pitch distance (mm) | Width of the strip (mm) |
1 | DN 8 | 10.3 | 0.18 | 8 | 11.3 | 2.7 | 31.8 |
2 | DN10 | 12.3 | 0.18 | 10 | 13.5 | 2.9 | 38.1 |
2 | DN 12 | 15 | 0.18 | 12.3 | 16.3 | 3.2 | 46.6 |
3 | DN 16 | 20 | 0.2 | 16.2 | 21.3 | 4.5 | 62.2 |
4 | DN 20 | 23.5 | 0.25 | 20 | 25 | 4.5 | 73.0 |
5 | DN 25 | 30 | 0.3 | 25 | 31.5 | 4.5 | 93.3 |
6 | DN 32 | 39.5 | 0.3 | 33 | 41 | 4.5 | 123.2 |
Related machines
We make all kinds of hose making machines including the following:
1. Elastomer Annular Hose Forming Machine: DN12-DN100
1). Diameter: DN12mm-DN100mm
2). Mill Length: 4m-8m
3). Hydraulic pressure: 3.5-4.5MPa
4). Operation mode: manual/automatic
2. Helical Hose Forming Machine:
1). Diameter: DN8-DN50mm
2). Thickness: 0.2-0.6mm
3). Speed: 1m/min
4). Welding machine: Panasonic TIG150 or Kemppi Finland(made in China)
5). Voltage rating: motor 380V, argon welder 220V
6). Electric power: 6KW
7). Adjustable speed: control by inverter
3. Hydraulic Hose Forming Machine: DN25-DN100
1). Range: DN25-DN100mm
2). Length 3.5-4.5m
3). Thickness: 0.2-0.5mm*2 layer
4). Lathe outline dimension: 4960mm * 560mm
4. DN50-300 Hydraulic Forming Machine
Diameter: DN50-300mm
No. of layers: single or double layers
Type of the bellows: annular bellows
Applications: for auto exhaust bellows, flexible metal hoses, and expansion joints
Control: PLC control
Length: ≤7500mm
Expanding medium: emulsified liquid
Forming speed: 5-10seconds per convolution
ID | DN50 | DN65 | DN80 | DN100 | DN125 | DN150 | DN200 | DN250 | DN300 |
Single wall thickness | 0.4 | 0.5 | 0.6 | 0.7 | 0.8 | 0.9 | 1.0 | 1.2 | 1.5 |
Double layer wall thickness | 0.25*2 | 0.3*2 | 0.4*2 | 0.50X2 | 0.60X2 | 0.70X2 | 0.80X2 | 0.90X2 | 1.0X2 |
Hydraulic Hose Making Machine | |
Machine Type No. | HLT-H-150 |
Technical Data | Application of the hose: water, oil, steam Size range: DN32 up to DN150 Wall thickness: 0.2-0.3mm Production speed:2.5~3.5m/min Strip thickness: 0.18-0.3mm Material: sus304, 321 and 316L Outer dimensions:15000*1100*1700 |
Packing details | Plywood box and standard pallet |
MOQ | 1 set |
Warranty | 1 year |
Payment terms | T/T, L/C, D/P, Western union |
