| Quantity: | |
|---|---|
LTM
Liquid Oxygen, Nitrogen, Argon, Carbon Dioxide
Low Pressure (0.1MPa≤p<1.6MPa)
New
Provided
2m3.3m3 5m3
755-3070kg
3 and 5
16mndr
Q345r
2.16 MPa
2.16 MPa
Jb/T 6898-2015
Video Technical Support, Online Support
Gas Storage
Provided
1 PCS
Available
20 Days
Standard Seaworthy Packages
3250*103081265
HLT
China Jiangsu
100 Pieces/ Month
Available | Customized Request
Product Description
The cryogenic storage tank is a vertical or horizontal double-layer vacuum insulation tank for storing liquid oxygen, nitrogen,argon,carbon dioxide and other media.Its main function is to fill and store low-temperature liquids. For the safe use of cryogenic storage tanks, gas hazardous characteristics, low-temperature protection effects, surrounding environmental conditions, and pressure vessel characteristics should be fully considered, and appropriate technical management measures should taken to ensure safe operation. Potential dangers such as leakage, over pressure,and explosion exist when the storagetnkii operation.If these hidden dangers are not handled in time,serious consequences will result.The use of cryogenic sto tanks should stricty implement the "Safety Rules for the Use of cryogenic Liquid Storage and Transportaion Equipment (JB/ T"6898-2015),and strengthen daily safety management.
| Model | Specifications | T ºC | Tank | DN | Support | Safety Valve Joint | Blowoff valve joint | ||
| volume m3 | Pressure | Height H | Hole size d | D | |||||
| HST-1/0.8 | 1 | 0.8 | 150 | 2180 | 800 | 24 | 560 | Rc11/2 | R 1/2 |
| HST-1/1.0 | 1 | 2180 | |||||||
| HST-1/1.3 | 1.3 | 2182 | |||||||
| HST-1/1.6 | 1.6 | 2182 | |||||||
| HST-2/0.8 | 2 | 0.8 | 150 | 2660 | 1100 | 24 | 740 | Rc11/2 | R 1/2 |
| HST-2/1.0 | 1 | 2660 | |||||||
| HST-2/1.3 | 1.3 | 2662 | |||||||
| HST-2/1.6 | 1.6 | 2662 | |||||||
| HST-3/0.8 | 3 | 0.8 | 150 | 2815 | 1300 | 24 | 950 | Rc2 | R3/4 |
| HST-3/1.0 | 1 | 2815 | |||||||
| HST-3/1.3 | 1.3 | 2817 | |||||||
| HST-3/1.6 | 1.6 | 2817 | |||||||
| HST-5/0.8 | 5 | 0.8 | 150 | 3811 | 1400 | 24 | 1050 | Rc2 | R1 |
| HST-5/1.0 | 1 | 3811 | |||||||
| HST-5/1.3 | 1.3 | 3813 | |||||||
| HST-5/1.6 | 1.6 | 3813 | |||||||
Q1.Are you manufacturer or trading company?
We are professional manufacturer in cryogenic equipment filed.
Q2.What's your advantage?
We provide you not only techology-leading,stable and reliable,cost-efficient equipment,but also solutionsand after-sales service.
Q3.Have your engineers participated in any foreign projects?
Yes,our engineers have more than 30 years experience in this filed and have participated in the design,manufacurer,installation
and comissioning of the equipment in Turkey,Russia,
Q4.How can I get the exact price of the product?
Please tell us your specific requirements and environmental data,so we can provide the most suitable products and solutions for
you.
